Condition: New
Automatic Grade: Automatic
Place of Origin: Jiangsu, China (Mainland)
Brand Name: ZHUOQI
Model Number: XH1000,XH2000
Voltage: 380V 50HZ
Power(W): 24~48kw
Dimension(L*W*H):25000*10000*4000mm(L*W*H)
Weight: 15000-250000kg
Certification: ISO9001
Warranty: 1 Year
After-sales Service Provided: Engineers available to service machinery overseas
| Packaging Details: | NUDE PACKING FOR SINGLE ,MACHINE,WOODEN CASE FOR SPARE PARTS |
|---|---|
| Delivery Detail: | 60 DAYS |
Name: Opener
Original: China
1).Single roll beater,card wire nail plate,beater motor
2).Roller feeding,motor
3)Transmission cotton fan
Name:Hopper
Orignal：China
1)Air pressure hopper
2)double roller outlet net
Name: Carding machine
Original: China
1)Air pressure hopper,double roller outlet net.
2)Feeding plate to feed,motor,,frequency transducer
3)Cylinder diameter1230mm,special motor:3.3kw
4)Flywheel stripping,motor:5.5kw
5)Stripping motor:3kw
Name:Air laid
Original:China
1)Fan motor
Name:Dipping machine
Original:China
1)Double net dipping,pressed by manual
2)Rubber roll transmission motor
1)Thermal oil cylinders24,Diameter:570mm,width 1400mm.10 with Teflon.
2)Transmission by gear,motor:,frequency transducer.
3)Provide rotating joint and metal tube.
Name:Winding machine
Orignal:China
1)Winding by single roll ,two operating position.
2)Drive by drying cylinder with friction plate.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
